VSI Series Sand Making Machine VSI Series Sand Making Machine

VSI Series Sand Making Machine

VSI series high efficiency vertical shaft impact crusher(sand maker)is the stone crushing equipment with domestic and international advanced technologies, which is researched on the basis of Germany advanced technology, combining the actual demand of China sand—making industry. It can supply high quality sand aggregate for high building, expressway (railway) construction, municipal engineering, large scale irrigation establishment, concrete batching plant and many other areas.

Contact Us e-mail

Advantages

  • Quality assurance, high efficiency and low consumption;

  • Unique design, easy to maintain;

  • Self-circulating system, focusing on environmental protection.

Technical Specifications

Model VSI 7611 VSI 8518 VSI 9526 VSI 1140 VSI 1145 VSI 1150
Capacity
(t/h)
Feed both at center and sides 80-180 140-260 200-380 300-520 350-610 360-650
Feed at center 40-90 70-130 100-190 160-260 180-355 190-365
Max.feeding size
(mm)
Soft material 35 40 45 50 50 50
Hard material 30 35 40 40 45 45
Rotation speed(r/min) 1700-1890 1520-1690 1360-1510 1150-1300 1150-1300 1150-1300
Motor power(kw) 4P   110 4P   180 4P   264 4P   400 4P   440 4P   500
Overall dimension(L×W×H)(mm) 4100×2250×2300 4160×2360×2500 4540×2500×2830 5500×2750×3100 5500×2750×3100 5500×2750×3100

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.

Model Capacity(t/h)
Feed both at center and sides Feed at center
VSI 7611 80-180 40-90
VSI 8518 140-260 70-130
VSI 9526 200-380 100-190
VSI 1140 300-520 160-260
VSI 1145 350-610 180-355
VSI 1150 360-650 190-365

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
