HLMC Series Line Spray Off-line Pulse Dust Collector

HLMC series line jet off-line pulse dust collector is a new and efficient bag dust collector developed on the basis of conventional pulse bag dust collector.

HLMC line jet off-line pulse dust collector is serving casting, metallurgy, machinery, electric power, building materials, mining, cement, chemical industry and other industries with its excellent performance. It is suitable for integrated dust collection with large air volume, high dust concentration and limited site, such as: sand making building and sand making line site compact occasions.

Contact Us e-mail

Advantages

  • Small floor area

  • High degree of automation

  • Good cleaning effect

  • Stable performance

Technical Specifications

Model Processing air volume
(m³/h)		 filtration velocity
(m/min)		 Total filtering area
(m²)		 Net filtering area
(m²)		 Dust concentration
of imported air
(g/Nm³)		 Dust concentration
of outlet air
(g/Nm³)		 Clean compressed air
Pressure (Pa) Air consumption(Nm³/min)
HLMC1000 48000~120000 0.8~2.0 1100 1000 <1000 <0.02 (5~7) x 105 2.1
HLMC1400 67200~168000 1500 1400 <1000 <0.02 2.1
HLMC1700 81600~204000 1820 1700 <1000 <0.02 3
HLMC2100 100800~252000 2280 2100 <1000 <0.02 3

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.

Model Processing air volume
(m³/h)		 filtration velocity
(m/min)		 Total filtering area
(m²)		 Dust concentration
of imported air
(g/Nm³)
HLMC1000 48000~120000 0.8~2.0 1100 <1000
HLMC1400 67200~168000 1500 <1000
HLMC1700 81600~204000 1820 <1000
HLMC2100 100800~252000 2280 <1000

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
